TECHNICAL PARAMETER/技术参数
MODEL型号 | SAR-400 | SAR-500 | SAR-650 | SAR-800 | SAR-800L | SAR-1000 | SAR-1200 |
Traction Motor 牵引电机 | 0.75KW | 0.75KW | 0.75KW | 0.75KW | 0.75KW | 1.5KW | 1.5KW |
Taction Speed 牵引速度 | 10-50m/min | ||||||
Crushing Motor 功率 | 4KW | 7.5KW | 7.5KW | 11KW | 11KW | 15KW | 22KW |
Crushing Chamber 塑料室尺寸 | 400*250mm | 515*250mm | 650*250mm | 800*250mm | 800*330mm | 1000*330mm | 1200*330mm |
Crush material Width 破碎料宽度 | ≦380mm | ≦500mm | ≦640mm | ≦790mm | ≦790mm | ≦980mm | ≦1180mm |
Crush material Thickness 破碎料厚度 | ≦2mm | ≦2mm | ≦3mm | ≦3mm | ≦3mm | ≦3mm | ≦3mm |
Rotary Blade 动刀 | 6 PCS | 6 PCS | 6 PCS | 6 PCS | 6 PCS | 6 PCS | 9PCS |
Fixed Blade 定刀 | 2 PCS | 2 PCS | 2 PCS | 4 PCS | 4 PCS | 4 PCS | 4 PCS |
Sieve Size 筛网 | 10mm | 10mm | 10mm | 10mm | 10mm | 10mm | 10mm |
Capacity 产量 | 50-100kg/h | 100-200kg/h | 200-300kg/h | 300-400kg/h | 400-600kg/h | 500-700kg/h | 500-800kg/h |
Blower Motor 风机功率 | 2HP | 2HP | 3HP | 5HP | 5HP | 7HP | 7HP |
Noise 噪音 | 80-90db | 80-90db | 80-90db | 80-90db | 80-90db | 80-90db | 80-90db |
